▶ Features:

Spindle driver can be configured with many kinds of expansion modules,such as Digital terminal expansion modules, Analog terminal expansion modules, Encoder feedback divider output, RS485 ModBus RTU,CANopen, GSM/GPRS modules,digital display module, double position loop module interfaces.

And also it can also be customized manufactured according to the user's specific applications, conveniently connected to CNC controller, HMI, PLC and other control devices.

Input Power	Rated Voltage/frequency	Three-phase 380V/480V;50Hz/60Hz
	Allowable Voltage range	+10%~-15%
	Allowable Frequency Fluctuation	± 5%
Control Features	Control Mode	PWM Vector Control
	Speed Adjustment Range	0.01~500Hz
	Speed Stabilization Precision	± 0.1%
	Acceleration/Deceleration time	0.05~3000Hz/s
	Torque Control	200% Rated torque output;Torque precision ±5%
	Position Control Precision	±1 Pulse
	Braking Mode	Powered Braking
	Overload Capacity	Twice Overload
I/Os	Digital Input	10 points , NPN or PNP(Optional)
	Digital Output	6 points , NPN
	Relay Output	2pcs ,DC30V/1A Or AC250V/1A
	Analog Input	2 inputs, A0:±10V; A1: 0~±10V Or 4~20mA (Optional)
	External Pulse Input	1 type ,ABZ phase pulse ,Pulse+Direction Or CW (Optional)
	Motor Encoder Input	1 type,RS422 TTL , Rotatry Connector(Optional)
	Motor Encoder Output	1 pcs,RS42TTL ,Output Frequency Range: 0~1MHz
	Ambient Temperature	-10℃ ~ +45℃
	Humidity	5~90%, not allow condensing
	Altitude	0~3000Meters,derated above 1000m, the rated output current shall be decreased by 1% for every rise of 100m
	Vibration	Under 20Hz:1G; 20~50Hz: 0.2G
