Usb Cnc Controller Mach 3 Axis

CNC Milling Controller: 1) ATC function: Umbrella Type/Arm Type/Linear Type/Servo Type/Special Tool Magazine 2) Support Rigid Tapping: Following Mode/Interpolate Mode 3) Support Stepper/Increment/Absolute/EtherCAT/Powerlink Servo for Feeding Axes 4) Scanning Function & Follow Mode & Auto Tool Setter/Probe

_20220707145050

Number of control axes	3 axes
Minimum programming	0.001mm
Maximum programming	± 99999.999mm
Top speed	30m / min
Feed speed	0.001-15m / min
Manual continuous	One axis or simultaneous multi-axis
Screen saver function	Screen saver function
Program editing	Male / English, relative / absolute programming
Pre-reading function	Short line preprocessing 10,000 lines
Compensation function	Knife compensation, between compensation, screw compensation, radius compensation
Communication function	RS232, U disk interface
Program editing	Male / English, relative / absolute programming
Tool functions:	1)Tool length compensation 2)Tool point radius compensation (C type)
Password protection	Multi-level password protection

1.-&(1000MC)(1)

Technical Features:

1. Support look-ahead forward control technology

2. Support RS232, USB, network three communication connections

3. Support statement macro program, programming is more concise

4. Support high-order spline fitting technology; port to realize file transfer, DNC processing, and USB.Provide system debugging function to facilitate machine tool assembly and debugging

5. Support rich composite trajectory cycle instructions, support blue wire processing

3.-(1000MC)

GH-1000TC

Multiple function:

It can realize the drilling/boring,roughing of roungroove / rectanglegroove ,finishing of full circle /rectangle, continous drilling of straight line /rectangle /arc etc.

FAQ

Q: Can I get some samples for test?
A: Yes, sample order is available for quality check and market test .

Q: Are you a factory or just a trading company?
A: We are a manufacturer and trader of automation products,such as servo motor, driver, stepper motor, DC motor, CNC controller, planetary gearbox,gear, rack and so on.

Q: How can I get quotation?

A: Leave us message with your purchase requirements and we will reply you within one hour on working time.
And you may contact us directly by Trade Manager.

Q: How about your quality control?

A: Our professional QC will check the quality during the production and do the quality test before shipment.

Q: How about warranty period?

A: We offer one year after-sales service, if broken in 1 year, we can offer spare parts free of charge to change.Offer technical support on line all the time.

If you have another question, pls feel free to contact us as below.
