Milling Computer Numerical Syntec Controller

CNC Milling Controller: 1) Support Dual analog voltage(0~10V)& C-axis for Spindle servo 2) Support RTCP mode 3) Support Stepper/Increment/Absolute/EtherCAT/Powerlink Servo for Feeding Axes 4) Scanning Function & Follow Mode & Auto Tool Setter/Probe

_20220707145050

Number of control axes	4 axes
Minimum programming	0.001mm
Maximum programming	± 99999.999mm
Top speed	30m / min
Feed speed	0.001-15m / min
Manual continuous	One axis or simultaneous multi-axis
Screen saver function	Screen saver function
Program editing	Male / English, relative / absolute programming
Pre-reading function	Short line preprocessing 10,000 lines
Compensation function	Knife compensation, between compensation, screw compensation, radius compensation
Communication function	RS232, U disk interface
Program editing	Male / English, relative / absolute programming
Tool functions:	1)Tool length compensation 2)Tool point radius compensation (C type)
Programming function	There are more than 100 G commands in total, including 12 common canned cycles, 19 special canned cycles and compound cycles, face milling, coordinate system rotation, scaling, mirroring, automatic tool length measurement, tool center point control, and inclined surface machining commands.The number of subroutine calls is 4. Class B user macro program

1.-&(1000MC)(1)

3.-(1000MC)

GH-1000TC

Multiple function:

It can realize the drilling/boring,roughing of roungroove / rectanglegroove ,finishing of full circle /rectangle, continous drilling of straight line /rectangle /arc etc.

FAQ

Q1: Do you support customized manufacturing?
A: Yes,we can customized manufacturing according to customer's requirment. We support to OEM your own company display interface and logo.

Q2:What's the MOQ?

A: MOQ: 1 pc

Q3:How to place the order?

A: Please contact with our sales to get the detail datasheet and confirm the part number of the encoder you need, then you can place the order online or underline.

Q4:What's the payment term?

A: We can accept T/T, Western Union and PayPal etc.

If you have any questions, pls feel free to contact us. We'll be sure to get back to you within an hour on a business day.
