SZGH-H2100-B-6 + Ground Rail | Coordinated Control — Large Structural Parts · Multi-Station Welding Line
SZGH-H2100-B-6 robot coordinates with ground rail as a 7th axis — extending the working envelope across multiple stations and enabling precise straight/curved path welding on large structural parts without repositioning.
Key advantages:
Ground rail coordinated control — robot + rail move as one synchronized axis; supports precise straight and curved welding trajectories across extended workpiece lengths
Covers full large structural part in one setup — excavator arms, box columns, machinery frames; no manual repositioning, no weld interruption
Multi-station production line ready — single robot services multiple fixtures along the rail; maximizes utilization per unit
±0.05mm repeatability on every pass — consistent bead quality maintained across the full rail travel length
Parameter | SZGH-H2100-B-6 |
Axes | 6 + Ground Rail (7th axis) |
Max Reach | 2,100 mm |
Repeatability | ±0.05 mm |
Path Support | Straight / Curved coordinated trajectory |
Application | Large structural parts · Multi-station line |
Axis Protection | Fully Enclosed (spatter-proof) |
Certification | CE / ISO 9001:2015 |
Share your workpiece size, station count & welding process — get a free ground rail welding solution in 24 hours →www.szghtech.com/szgh-h2100-b-6
